Multi-Stage Centrifugal Compressor

Focusing on energy storage and other related fields, the increasing demand for higher compression ratios cannot be met by single-stage centrifugal compressors. Therefore, a multi-stage centrifugal compressor design is required to achieve the desired performance.

Solution

Based on TurboTides’ multi-stage centrifugal compressor module, rapid distribution of multi-stage compression ratios is conducted. Coupled with an integrated design platform, fast design, simulation, and modeling of multi-stage configurations are performed, facilitating the quick implementation of the project.
